Choosing a microscope for any specialist application can be daunting, and there is so much ‘expert’  advice out there on the Internet which allows anyone who wishes, to claim to be an instant ‘expert’. Both the directors of Brunel Microscopes worked for many years in pathology laboratories and are professionally qualified and the reputation of our company is of paramount importance to us. We will only advise you to buy what you need not what we would like to sell you. Microscopes are a bit like motor cars - they all have the same basic construction  -  4 wheels, an engine, gear box and steering wheel etc: Your choice of car depends on whether you want to win the next F1 race or go to the supermarket to do the weekly shop. Identifying fish parasites is akin to the supermarket shop in microscopy terms and the instruments that we have listed below are more than able to do the job. . Having said that there are always those that like the look of a Bentley on the drive, and we cater for those as well.

Beginners Tip

You have the choice of one eyepiece (monocular), two (binocular) or three - with one for a camera (trinocular) Some points to think about:

• Binocular is more expensive but it does not make the image better however it is more restful on the eyes if you use the microscope a lot
• You can also use cameras on the monocular and binocular microscopes - see the accessories page
• You can also take images using your mobile phones using our adapter - see the accessories page

• All the microscopes above have Royal Microscopical Society standard objectives that are corrected for colour aberration - these are called achromatic. The SP21 has a x100 objective available as an accessory.
• They don’t have bulbs, they have Light Emitting Diodes (LED) which have a life time guarantee.
• Research  microscopes have plan achromatic objectives that are also corrected for flatness of field.
• Research microscopes also have Kohler lighting which is good for publication standard photographs. For those wanting to take microscopy further or who simply want the best, the SP100 - the ‘Bentley' of the microscope world would be the deluxe answer.
• The SP22D digital microscope has everything included to get it working on computers with Windows O/S. We also provide IT support should it be needed.

The SP100 is a professional standard trinocular microscope with plan achromatic objectives x4, x10, x40 and x100 (oil immersion) and wide field x10 eyepieces. Magnification range of x40 to x1000. The slide platform is a full mechanical stage that moves the slide by drop down coaxial controls. The Kohler lighting is LED with brightness control and it has a fully adjustable substage condenser with iris diaphragm. Coaxial coarse and fine focus controls with a safety stop to protect the slides. Carrying case included

Prices:     Microscope only - £665.00 + vat Microscope + Worm Kit  -  £698.33 + vat     Worm Egg Kit only - £43.33+ vat

Brunel SP100 Trinocular

Identify and count faecal worm eggs in cattle, mammals and birds

A web site owned and maintained by Brunel Microscopes Ltd

Worm Egg  Microscopy

Brunel SP21 Monocular

The SP21 has 3 standard RMS screw thread objectives x4, x10, x40 with 2 eyepieces x10 and x20 which gives a magnification range of x40 to x800.

The slide platform is a full mechanical stage that moves the slide by drop down coaxial controls. The lighting is LED with brightness control and it has a full substage condenser with iris diaphragm. Coarse and fine focus controls with a safety stop to protect the slides. Aluminium case as an extra accessory.

Prices:     Microscope only - £150.00 + vat Microscope + Worm Kit  -  £193.33 + vat     Worm Egg Kit only - £43.33 + vat Aluminium carrying case - £36.67

Brunel SP35 Binocular

The SP35 is a binocular microscope with 2 x10, and 2 x20 eyepieces and four objectives x4, x10, x20 and x40 giving an overall magnification range of x40 to x800.

The slide platform is a full mechanical stage that moves the slide by drop down coaxial controls.

The lighting is LED with brightness control and it has a full substage condenser with iris diaphragm. Separate coarse and fine focus controls with a safety stop.

Prices:     Microscope only - £245.00 + vat Microscope + Worm Kit  -  £288.33 + vat     Worm Egg Kit only - £43.33 + vat

Brunel SP52 Trinocular

The SP52 is a trinocular microscope with 4 objectives x4, x10, x40 and x100 and x10 eyepieces giving a magnification range of x40 to x1000. The slide platform is a full mechanical stage that moves the slide by drop down coaxial controls. The lighting is LED with brightness control and it has a full substage condenser with iris diaphragm. Coaxial coarse and fine focus controls with a safety stop to protect slides. The trinocular tube allows a camera to be attached whilst still viewing. Carrying case included.

Prices:     Microscope only - £398.33 + vat Microscope + Worm Kit  -  £438.33 + vat     Worm Kit only - £43.33+ vat

Brunel SP22D Digital

The SP22 ia a monocular microscope with an inbuilt digital camera. The microscope connects by USB lead directly to a computer Windows 7,8,10 and 11 but not suitable for Apple MAC. All leads, software and IT support included. Magnification range of x40 to x1000. The slide platform is a full mechanical stage that moves the slide by drop down coaxial controls. The lighting is LED with brightness control and it has a full substage condenser with iris diaphragm.. Separate coarse and fine focus controls with a slide safety stop.

Prices:     Microscope only - £286.67 + vat Microscope + Worm Kit  -  £325.00 + vat     Worm Kit only - £43.33+ vat

Beginners Tip
